Interscience Scan 300 Automatic Colony Counter

Name: Interscience Scan 300 Automatic Colony Counter
Brand: INTERSCIENCE
SKU: COL1034
Price: 8314.80 EUR

Code: COL1034 D2-0

Scan® colony counters allow for a quick, complete and accurate reading of your Petri dishes. Counting colonies is no longer time-consuming. With a digital camera and high technology software, ...

ADD

Your Price

€6,760.00 EACH

€8,314.80 inc. VAT

REQUEST

REQUEST A QUOTE

OVERVIEW
SPECIFICATIONS
DOCUMENTS

Scan® colony counters allow for a quick, complete and accurate reading of your Petri dishes. Counting colonies is no longer time-consuming. With a digital camera and high technology software, they can be linked to a PC via a USB connection. They count all colonies on a Petri dish in less than 1 second and provide a complete, fast, accurate and traceable reading of the result.

High performance: count colonies of numerous media
Fits any type of dish: automatic adjustment of contrast and lighting
Instant results: up to 1000 colonies detected in 1 second
Easy to use: all functions in 1 single window
Dark Field technology and high definition live images for optimum visualisation
Traceability and reporting
Pre-set parameters for different media preparations and test conditions
Scan® 500 and Scan® 1200 can read chromogenic agar and differentiate colonies by colour
3 models adapted to your needs
6 combinations of lighting and backgrounds
Brightness, contrast and sensitivity are automatically optimised by the software
Scan® 500 and Scan® 1200 can be used as an inhibition zone reader to test for efficiency of antibiotics

Code	COL1034	COL1036	COL1038
Model	Scan® 300	Scan® 500	Scan® 1200
Stainless steel body	Yes	Yes	Yes
LIMS/SIL connection	Yes	Yes	Yes
USB connection	Yes	Yes	Yes
Counting on pour, surface, Spiral and circle plates Petri dishes	Yes	Yes	Yes
Counting on chromogenic dishes	-	Yes	Yes
Counting on Petriﬁlm™, Compact Dry™, MC-Media Pads™, easyPlate™, ﬁltration membranes	-	-	Yes
Inhibition zone reader	-	Yes	Yes
Counting	Automatic with manual control
Automatic separation of clustered colonies	Yes	Yes	Yes
Creation of polygonal exclusion zones	Yes	Yes	Yes
Manual control to add or subtract colonies	Yes	Yes	Yes
Counting time	Up to 1000 colonies per second
Minimal size of colony	0.1mm		0.05mm
Antibiotic disc detection	-	Automatic with possibility to add or remove manually antibiotics
Automatic detection of antibiogram support	-	Disks (several brands simultaneously), wells, peni-cylinder (steel, plastic)
Display resolution	-	± 0.1mm
Inhibition zone measurement accuracy	-	± 0.3mm
Number of antibiotic paper disks	-	Up to 7 antibiotics on a Ø 90 mm Petri dish
Reading time	-	7 inhibition zone reading between 1 to 3 seconds
Interpretation system	-	CA-SFM Human health / EUCAST / CA-SFM Veterinary / CLSI (Clinical, Laboratory Standards Institute) / Customisable list
Colour camera	CMOS		HD CCD
Lens	M12 Lens		HD Japanese Lens
Zoom	x28
Resolution	1 MP		1.2 MP
White LED Lighting technology	Dark Field
LED Lighting system	Automatic with 6 combinations, top and/or bottom light, white or black background
Petri dish dimensions	Ø 55mm - Ø 90mm
Colour detection	-	7 colours on the same dish + 1 colour to exclude
USB Data export	to LIMS, PDF report, jpg, png and bmp images, Excel™ recountable session
Data security	Modified data traceability in conformity with 21 CFR part 11
Results/traceability	Image / sample number / comments / date / time	Image / sample number / comments / date / time / antibiotic name / bacterial name / diameter read / SIR categorised result with colour code / minimum and maximum critical diameter
In compliance with	21 CFR Part 11, ISO 7218 and AOAC 977.27
